Quality Assurance

 HORIZONTAL PUMPS
Features :
All The Wetted parts Are Made From Investment Castings Using Lost Wax process, Giving Excellent Surface Finish, Sound Castings, Giving Minimum Resistance to Flow Resulting in better Efficiencies.
Maximum Interchangeability, Gives Minimum Spare parts Inventory.
Greater Quality Control and Accuracy in Production Of Every pump With the Modern Machining Operations.
Back Pull – Out Design, permits Quick Inspection or Repairs Of Rotating Elements Without Disturbing Electrical and Piping Connections Resulting in Minimum Down – Time
Hydraulic Performance Maintained by Simple External Axial Adjustment Of Impeller Wear.
Exclusive Balanced Thrust.
Standard Dimensions , Cut Layout design Cost.
Standard Foundation Save Installation and Drawing Time, Talent and Money.
Fully Open Impeller With Back pump – Out vanes Reduces Stuffing Box Pressure and prevents Entrance Of Solids and Meets Low NPSH Requirement.
 SCP LC
Download Brochure
Top
 SCP MD
Specification
Shown below are the Constant dimensions that apply to investa type – SCP, group – MD Standardized Chemical Pumps. Investa’s Key Factor Of Design is the Pump Standardization Which leads to Maximum dimensional Interchangeability and Flexibility Benefiting the Ultimate User.
One Length For All Sizes (Refer GAD ) 600mm.
One Coupling bore For All Size 28mm.
One Bolt Size For Holding Pumps to base M-14.
One Bolt Spacing For Holding All Pumps 305mm.
One Spacer Coupling Length For all Sizes 100mm.
Download Brochure
Top
 SCP SM
Specification
Shown below are the Constant dimensions that apply to investa type – SCP, group – SM Standardized Chemical Pumps. Investa’s Key Factor Of Design is the Pump Standardization Which leads to Maximum dimensional Interchangeability and Flexibility Benefiting the Ultimate User.
One Length For All Sizes (Refer GAD ) 445mm.
One Coupling bore For All Size 22mm.
One Bolt Size For Holding Pumps to base M-12.
One Bolt Spacing For Holding All Pumps 185mm.
One Spacer Coupling Length For all Sizes 100mm.
Download Brochure
Top
